Adoption of insulated needle without damage of epidermis minimizes downtime.
Application of high density energy reduces irradiation time of high frequency and shortens the treatment time epochally resulting in increasing the treatment effect and minimizing pain.
Needle insert system accessible to both automatic mode and convenience according to the lesion and treatment area.
Application of powerful motor to insert needle enables you to insert needle uniformly even for curved dermis.
Optimized treatment for the purpose of dermis coagulation shows an excellent effect in the treatment of gular suture, laugh line, philtrum wrinkle, etc which were difficult to treat with other devices.
| Model | Ashley |
| Energy | 32J(Max.power) |
| Repeat time | 0.5sec-3.0ms,OFF |
| Pulse duration | 2-100ms / (Single / Double Pulse Mode) |
| Frequency | 1MHz/2MHz (Selectable) |
| Density level (MFR) | 36dots(Needle6x6) |
| Enable Operation Shots | One needle can use up to 3000 shots for one patient |
| Operating Mode | Auto |
| Manual | |
| Operating area (MFR) | Square (13mm×13mm) |
| Operating area (NFR) | Square |
| Save mode | SMART MODE, M1-M5 |
| Depth control | 0.5-4mm |
| Electrical Requirements | 100/220v, single phase,50/60hz |
| Dimensions | 380(w)x440(D)X1150(H) mm |
| Weight | 22kg |
| Display | Touch screen 10.2 Inches color LCD |
